Application:
It is suitable for granule, like rice, sugar, salt, coffee bean etc.
Technical parameters:
| Model | QUA-4 |
| Single Dump Max. (g) | 20-1500G |
| Weighing Accuracy(g) | 0.2-2g |
| Max. Weighing Speed | 10-45wpm |
| Weigh Hopper Volume | 3000ml |
| Control Panel | 5.7” LCD Touch Screen (WEINVIEW) |
| Max. mix-products | 4 |
| Power Requirement | 220V/50/60HZ 8A/800W |
| Packing Dimension(mm) | 996(L)*1032(W)1032(H) |
| Gross/Net Weight(kg) | 200/180kg |
Special features:
1. Make mix different products weighing at one discharge;
2. Adopt no-grade vibrating feeding system to make products flowing more fluently;
3. Program can be freely adjusted according to production condition;
4. Can be remote-controlled and maintained through internet;
5. Adopt high precision digital load cell;
6. Stable PLC system control;
7. Color touch screen with Multilanguage control panel;
8. Sanitation with 304﹟S/S construction
9. The parts contacted products can be easily mounted without tools;
10. IP65 construction.
