Application:
Suitable for packaging many different kinds of products; such as puffy food, shrimp roll, peanut, popcorn, cornmeal, dried fruit, seed, small hardware, dumplings, vegetable, fruits and sugar etc. Which shape is roll, slice and granule.
Technical Parameter:
Type | QUA-520 |
Bag length | 80-370mm(L) |
Bag width | 80-250mm(W) |
Max width of roll film | 520mm |
Packing speed | 5-60bags/min |
Air consumption | 1.0 mpa |
Gas consumption | 0.4m³/min |
Power voltage | 220VAC/60HZ |
Power | 2.7KW |
Dimension | (L)1175mm*(W)1530mm*(H)1670mm |
Deadweight of machine | 800Kg |
Technical characteristics:
- PLC control with stable reliable biaxial high accuracy output and color touch screen, bag-making, measuring, filling, printing,cutting , finished in one operation.
- Separate circuit boxes for pneumatic control and power control. Noise is low, and the circuit is more stable.
- Film-pulling with servo motor double belt: less pulling resistance, bag is formed in good shape with better appearance, belt is resistant to be worn-out.
- External film releasing mechanism: simpler and easier installation of packing film.
- Adjustment of bag deviation just needed to be controlled by the touch screen. Operation is very simple .
- Close down type mechanism , defending powder into inside of machine.
