Technology Charateristic:
- Full-automatic weigh-form-fill-seal type, efficient and simple to use.
- Use famous brand electric and pneumatic components, stable and long life circle.
- Use superior mechanical components, reduce the wear out loss.
- Easy to install film, auto correcting the excursion of the film.
- Apply advanced operating system, easy to use and reprogramable.
- The heat transfer printer & automatic film correction motor and anti-static device are for optional.
Technical parameters:
| Type | QUA-420 |
| Bag length | 50-300mm(L) |
| Bag width | 50-200mm(W) |
| Max width of roll film | 420mm |
| Packing speed | 5-70bags/min |
| Air consumption | 0.65mpa |
| Gas consumption | 0.3m³/min |
| Power voltage | 220VAC/50HZ |
| Power | 2.2KW |
| Dimension | (L)1080mm*(W)1300mm*(H)1400mm |
| Deadweight of machine | 600Kg |
