Automatic Horizontal Packing Machine

Automatic Horizontal Packing Machine


Suitable for Packing various kinds of regular objects like bread, biscuits, pies, chocolate, instant noodles, moon cakes, drugs, mask,  daily appliances, industrial parts, paper boxes, plates.

Packaging samples:

Technical parameters:

Fiml width250mm250mm350mm350mm
Bag length65-90 or 120-280mm90-220mm56-190 or 120-280mm90-120 or 150-330mm
Bag width30-110mm30-110mm50-160mm50-160mm
Product heightmax.40mmmax. 55mmmax.40mmmax. 60mm
Film roll dia.max.320mmmax.320mmmax.320mmmax.320mm
Packing speed40-230bags/min40-230bags/min40-230bags/min40-230bags/min
Machine size(L)3770×(W)670×(H)1450mm(L)4020×(W)800×(H)1450mm
Machine weight800Kg900Kg



Technology Charateristic:

1.Double transducer control, flexible bag length cutting, operator needn’t to adjust the unloadingworking, saving time and saving films.

2.Human-machine operation, convenient and quick parameter setting.

3.Self diagnosis failure function, clear failure display.

4.High sensitivity optical electric color mark tracking,digital input cut position which makes the sealing and cutting more accurate.

5.Separate PID control to temperature, suitable for various packing materials.

6.Stopping the machine in selected position, no sticking to the knife and no waste packing film.

7.Simple driving system, reliable working, convenient maintenance.

8.All the controls are achieved by software, convenient for function adjusting and upgrading.
