Main Characters:
- The equipment adopts the brand-newly designed filling technique and the service.
- Special bypass design ensures lower energy consumption and higher yielding results.
- Computer-aided operation with the simple technical design makes for easy maintenance of the equipment.
- In addition, such equipment has compact structure, which can be easily moved because of small volume.
Technical Parameters:
| Items | Content |
| Nitrogen Capacity | 5Nm³/h |
| Power | 5KW |
| Nitrogen Purity | 99.5-99.9%% |
| Dew Point | ≤-38℃ |
| Air Source Pressure | 0.8-1.0Mpa |
| Nitrogen Pressure | 0.1-0.65Mpa(adjustable) |
| Dimensions | 590×570×1230mm(L×W×H) |
| Voltage | 220V/1Ph/50HZ |
| Weight | 150kg |
