Application:
Suitable for all kinds of powder, such as flour, coffee powder, milk powder, protein powder, starch, spice etc.
Packaging samples:
Technical parameters:
| Type | QUA-520 |
| Bag length | 80-370mm(L) |
| Bag width | 60-250mm(W) |
| Max width of roll film | 520mm |
| Packing speed | 5-60bags/min |
| Air consumption | 0.65mpa |
| Gas consumption | 0.4m³/min |
| Power voltage | 220VAC/60HZ |
| Power | 3KW |
| Dimension | (L)1500mm*(W)1170mm*(H)1500mm |
| Deadweight of machine | 800Kg |
Technology Charateristic:
- CE certification.
- Panasonic servo motor driven auger filler.
- Panasonic servo motor drawing film, double bellt, faster and more stable.
- Mitsubishi PLC computer touch screen, easy to operate.
- Siemens frequency changer, all the spare parts, are international brands.
- The forming tube with five-sides design, very easy to make the perfect stand up bag style.
- The heat transfer printer & automatic film correction motor and anti-static device are for optional.
